Description LH CCW Rotation, 3/4in-16 Fuel Discharge Hole, 180 Bars Max, 24 Liter/Minute, 11-Tooth Cat 3406, 5.5 to 6 GPM, 2175 PSI Uses Seal Kit 465.4104 Specifications No additional information available. Where Used This item is not featured in any schematics. Applications There is no application data for this product....

Description Tandem Steering and Fuel Pump, D11, D13 Engines 2685 PSI-185 Bars Rated LH-CCW Specifications Attribute Value Pumps Type ZF Type Displacement (CC) 15cc (.91 cir) Flow (GPM) 3.70 (14 lpm) Relief (PSI) 2610 (180 bar) Rotation LH CCW Shaft Type N/A Housing Cover Type N/A Inlet Port M16 1.5-6H...

Description Tie Rod End Specifications Attribute Value Rod OD (A) 1-1/8” Type 1 Thread Pitch & Direction 12 (LH) Center to End (B) 5.000” Height of Taper (C) 1.930” Taper Minor Dia. (D) 0.760” Taper Major Dia. (E) 0.876” Taper Length (F) 0.896” Stud Thread (G) 5/8”-18 Drop (H) N/A...

Description Used with 463.DS2089 Specifications Attribute Value Rod OD (A) 1-1/4” Type 1 Thread Pitch & Direction 12 (RH) Center to End (B) 7.500” Height of Taper (C) 2.400” Taper Minor Dia. (D) 1.080” Taper Major Dia. (E) 1.250” Taper Length (F) 1.360” Stud Thread (G) 7/8”-14 Drop (H) N/A Item...

Description FH941 and FH946 Axles Etc. Incules 2-MLP7113 and 2-MLP711 and 4-460.75 Product Overview Automann King Pin Kits provide all parts necessary for maintaining your heavy duty fleet. The king pin allows connection between the steering knuckle and the axle of the truck, while transferring immense force and maintaining steering...

Description RH CW Rotation, 3/4in-16 Fuel Discharge Hole, 180 Bars Max, 24 Liter/Minute, 11-Tooth Cummins, 5.5 to 6 GPM, 2175 PSI Uses Seal Kit 465.4104 Specifications Attribute Value Pumps Type ZF Type Displacement (CC) 34cc (2.07 cir) Flow (GPM) 6.34 (24 lpm) Relief (PSI) 2610 (180 bar) Rotation RH CW...

Description Vickers Type Right Hand Clockwise CCW Rotation Specifications Attribute Value Pumps Type VIC Type Displacement (CC) 29.7cc (1.81 cir) Flow (GPM) 7.93 (30 lpm) Relief (PSI) 2030 (140 bar) Rotation RH CW Shaft Type 11-Tooth Housing Cover Type N/A Inlet Port 3/4-16UNF Outlet Port 1-5/16-12UN Housing 90 CW Outlet...

Description Tie Rod End Specifications Attribute Value Rod OD (A) 1-1/4” Type 1 Thread Pitch & Direction 12 (LH) Center to End (B) 7.500” Height of Taper (C) 2.400” Taper Minor Dia. (D) 1.080” Taper Major Dia. (E) 1.250” Taper Length (F) 1.360” Stud Thread (G) 7/8”-14 Drop (H) N/A...

Description Vickers V10F Type Intlet 1.00in NPT, Inlet 3/4-16 and 1/2in NPT Tank Port Outlet Inline with Inlet Port Viewed from Cover End Shaft Turns Right Specifications Attribute Value Pumps Type VIC Type Displacement (CC) 20cc (1.22 cir) Flow (GPM) 5.94 (22.5 lpm) Relief (PSI) 1595 (110 bar) Rotation RH...

Description Includes Caps 4-460.45P6 1.794in x 9.06in King Pin Includes Upper Draw Key 2-MLP7117 and Lower 2-MLP7119 Product Overview Automann King Pin Kits provide all parts necessary for maintaining your heavy duty fleet. The king pin allows connection between the steering knuckle and the axle of the truck, while transferring immense...

Description V20F Vickers Type 2 Bolt Flange, 1-1/4 NPT Inlet, 3/4in-16 Outlet which is Inline with Inlet and 1/2in NPT for Tank Port Side 9 GPM at 1200RPM Shaft Splined RH Rotation Specifications Attribute Value Pumps Type VIC Type Displacement (CC) 29.7cc (1.81 cir) Flow (GPM) 5.94 (22.5 lpm) Relief...

Description Includes Caps 4-460.45P6 1.794in x 9.06in King Pin Icludes Upper Draw Key 2-MLP7117 and Lower 2-MLP7119 Product Overview Automann King Pin Kits provide all parts necessary for maintaining your heavy duty fleet. The king pin allows connection between the steering knuckle and the axle of the truck, while transferring immense...

Description RF21 Axle Etc Specifications No additional information available. Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name Part Number Notes McNeilus & Man 1139031 Tie Rod End RH Meritor A1344F1020 Tie Rod End RH Meritor A1344G1021...

Description Vickers V10F Mack 11 Tooth, 1750 PSI, Flow Rate 5, Rotation Right Hand, 1.0in Inlet Specifications Attribute Value Pumps Type VIC Type Displacement (CC) 22.8cc (1.39 cir) Flow (GPM) 5.28 (20 lpm) Relief (PSI) 1740 (120 bar) Rotation RH CW Shaft Type 11-Tooth Housing Cover Type N/A Inlet Port...

Description Includes Caps 4-460.45P6 1.794in x 9.06in King Pin Includes Upper Draw Key 2-MLP7117 and Lower 2-MLP7119 Product Overview Automann King Pin Kits provide all parts necessary for maintaining your heavy duty fleet. The king pin allows connection between the steering knuckle and the axle of the truck, while transferring immense...

Description Vickers V20F Mack 11 Tooth, 2000 PSI, Flow Rate 6, Rotation Right Hand, 1-1/4in Inlet Specifications Attribute Value Pumps Type VIC Type Displacement (CC) 29.7cc (1.81 cir) Flow (GPM) 5.28 (20 lpm) Relief (PSI) 2320 (160 bar) Rotation RH CW Shaft Type 11-Tooth Housing Cover Type N/A Inlet Port...

Description Anti-Tilt RF21 Axle Etc RH Threaded use with 462.ES9329 Adapter Used in 463.DS9907 Assembly Specifications Item Used In Automann # Image Product Name 463.DS9907 Cross Tube Assembly Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name Part Number Notes IHC...

Description LH Does one Side Only for Opposite RH Use 460.539B Includes 1-460.T523 Composite type Thrust Bearing 10-14K Model 3 Product Overview Automann King Pin Kits provide all parts necessary for maintaining your heavy duty fleet. The king pin allows connection between the steering knuckle and the axle of the truck,...

Description Vickers V10 Mack 11 Tooth, 2000 PSI, Flow Rate 5, Rotation Right Hand, 1.0in Inlet Specifications Attribute Value Pumps Type VIC Type Displacement (CC) 16cc (.97 cir) Flow (GPM) 5.02 (19 lpm) Relief (PSI) 2030 (140 bar) Rotation RH CW Shaft Type 11-Tooth Housing Cover Type N/A Inlet Port...

Description 1.0-16 Inch, 4.0in C to End, Minor 1.080, Major 1.250 Hgt of Taper 2.744 Can Try with 462.ES9946 Specifications No additional information available. Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name Part Number Notes Terex...
