Description Bar in End 1Large Dia.Taper 1.10in Small Dia.Taper 0.965in with7/8in-14 Nut End 2 Large Dia. Taper 1.10in Small Dia. Taper 0.965in with7/8in-14 Nut 47-4900 Series Specifications No additional information available. Where Used This item is not featured in any schematics. Applications There is no application data for this product....

Description Tie Rod End Specifications Attribute Value Rod OD (A) 1-1/4” Type 4 Thread Pitch & Direction 12 (RH) Center to End (B) 9.320” Height of Taper (C) 2.470” Taper Minor Dia. (D) 0.967” Taper Major Dia. (E) 1.102” Taper Length (F) 1.080” Stud Thread (G) 7/8”-14 Drop (H) 0.780”...

Description King Pin Kit Product Overview Automann King Pin Kits provide all parts necessary for maintaining your heavy duty fleet. The king pin allows connection between the steering knuckle and the axle of the truck, while transferring immense force and maintaining steering geometry. This kit makes aftermarket installation easy and...

Description Drag Link 16.840in C to C IHC Specifications No additional information available. Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name Part Number Notes IHC 489023C91 Drag Link IHC 16.84Ó IHC FDL1034 Drag Link IHC 16.84Ó...

Description Tie Rod End Specifications Attribute Value Rod OD (A) 1-1/4” Type 4 Thread Pitch & Direction 12 (LH) Center to End (B) 9.320” Height of Taper (C) 2.470” Taper Minor Dia. (D) 0.967” Taper Major Dia. (E) 1.102” Taper Length (F) 1.080” Stud Thread (G) 7/8”-14 Drop (H) 0.780”...

Description Model FBC Kit Consists of: 2-460.456B1 Press Fit Application Pin, 2-MHS50581, 2-MHS50528, 4-G1803, 2-460.T1822S, 1-BKC340214GR8K4, 8-460.S17B Product Overview Automann King Pin Kits provide all parts necessary for maintaining your heavy duty fleet. The king pin allows connection between the steering knuckle and the axle of the truck, while transferring immense...

Description ST10, ST13, ST20 Consists of: 2-460.447B2 Draw Kit Application Pin, 2-MHS50581, 2-MHS50528, 4-G1803, 2-460.T1822S, 1-BKC340214GR8K4, 8-460.S17B, 2-MLP7114, 2-FLN101 Product Overview Automann King Pin Kits provide all parts necessary for maintaining your heavy duty fleet. The king pin allows connection between the steering knuckle and the axle of the truck, while...

Description One Replaceable End Can Try 462.ES2091RS for Adjustable End Specifications Attribute Value C to C 17.880” C to C (B) N/A C to E or E to E 14.500” Type 1-S E to E (A) 14.500” Shaft Dia. (A) 1.811” # Rep. Ends 1 Male/Female Male Shaft Thread 1-1/4”-12...

Description For Models: HLUS2, HLUR2T, UCL, UC2, 3, 4 Does Not Include King Pin 460.447B2 Can use with 460.77 Product Overview Automann Bearing Kits provide all parts necessary for maintaining your heavy duty fleet. All these components help assist with maintaining the steering knuckle connection to the axle of the truck....

Description Tie Rod End Specifications Attribute Value Rod OD (A) 1-5/8” Type 4 Thread Pitch & Direction 12 (RH) Center to End (B) 15.100” Height of Taper (C) 2.284” Taper Minor Dia. (D) 0.975” Taper Major Dia. (E) 1.100” Taper Length (F) 1.122” Stud Thread (G) 7/8”-14 Drop (H) 1.575”...

Description Steer Code 05344 Uses Short End 462.ES2203R and Long End Specifications Attribute Value C to C 17.130” C to C (B) N/A C to E or E to E 14.562” Type 1-S E to E (A) 14.500” Shaft Dia. (A) 1.889” # Rep. Ends 1 Male/Female Male Shaft Thread...

Description ST10, ST13, ST20, 1.810in x 9.500in, with Draw Key Slot Use MLP476 Specifications Item Used In Automann # Image Product Name 460.447B King Pin Kit Hendrickson/Turner Where Used This item is featured in the following schematics: Name Type Hendrickson Turner Lift Axle HLUC Composilite™ SC, ST, STS, FBC, FX...

Description Tie Rod End Specifications Attribute Value Rod OD (A) 1-5/8” Type 4 Thread Pitch & Direction 12 (LH) Center to End (B) 15.100” Height of Taper (C) 2.284” Taper Minor Dia. (D) 0.975” Taper Major Dia. (E) 1.100” Taper Length (F) 1.122” Stud Thread (G) 7/8”-14 Drop (H) 1.575”...

Description For ST, U, UT, UC with 2-Piece Cast Knuckle and Draw Keyed Pin Consists of: Consists of: 2-FLN101, 2-MLP476 Product Overview Automann King Pin Kits provide all parts necessary for maintaining your heavy duty fleet. The king pin allows connection between the steering knuckle and the axle of the...

Description Uses 462.ES2203R Short End and 462.ES3214R Long End CO9670 and COF9670 -1981-88 Same Stud B.Ends Small Dia .967in and Large Dia 1.102in with 7/8-14 Nuts Specifications No additional information available. Where Used This item is not featured in any schematics. Applications There is no application data for this product....

Description Tie Rod End Specifications Attribute Value Rod OD (A) 1-1/4” Type 1 Thread Pitch & Direction 12 (RH) Center to End (B) 7.562" Height of Taper (C) 2.687" Taper Minor Dia. (D) 0.968" Taper Major Dia. (E) 1.250" Taper Length (F) 1.375" Stud Thread (G) 7/8”-14 Drop (H) N/A...

Description Can Try 463.ES2090L Specifications Attribute Value Rod OD (A) 1-1/4” Type 1 Thread Pitch & Direction 12 (LH) Center to End (B) 7.562" Height of Taper (C) 2.687" Taper Minor Dia. (D) 0.968" Taper Major Dia. (E) 1.250" Taper Length (F) 1.375" Stud Thread (G) 7/8”-14 Drop (H) N/A...

Description GD, GH Specifications Attribute Value Rod OD (A) M44 Type 3, 4 Thread Pitch & Direction 2.0 (RH) Center to End (B) 8.125” Height of Taper (C) 2.634” Taper Minor Dia. (D) 1.000” Taper Major Dia. (E) 1.100” Taper Length (F) 1.340” Stud Thread (G) M20-1.5 Drop (H) 1.476”...

Description GD, GH Specifications Attribute Value Rod OD (A) M44 Type 3, 4 Thread Pitch & Direction 2.0 (LH) Center to End (B) 8.125” Height of Taper (C) 2.634” Taper Minor Dia. (D) 1.000” Taper Major Dia. (E) 1.100” Taper Length (F) 1.340” Stud Thread (G) M20-1.5 Drop (H) 1.476”...

Description Includes 2-OEM Type 7X1010 at 2-1/2in OAL, and 7X1011 at 3-11/32 OAL which is Replaced by MLP7102 7X1002 Draw Keys RSS232T 8K 8K Knuckles Product Overview Automann King Pin Kits provide all parts necessary for maintaining your heavy duty fleet. The king pin allows connection between the steering knuckle...
