Continental Air Spring Rolling Lobe 75269

Continental Air Spring Rolling Lobe 75269

No Review
SKU: 566.CT75269
Vendor: Continental
Availability: Many In Stock
Regular price
$308.67
Regular price
$463.00
Sale price
$308.67
Ask An Expert

Free Shipping

Free standard shipping on orders over $249.

Excludes: Oversize Items (Brake Drums, Hubs, Body Parts, Exhaust, etc.)

Estimated to be delivered in 2-3 Business Days once shipped.

Typical lead time before shipped is 1-2 Business Days.

Free Returns

Learn More.

10 customers are viewing this product

Returns Policy

You may return most new, unopened items within 30 days of delivery for a full refund. We'll also pay the return shipping costs if the return is a result of our error (you received an incorrect or defective item, etc.).
You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).
If you need to return an item, simply login to your account, view the order using the "Complete Orders" link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.

Shipping

We can ship to virtually any address in the world. Note that there are restrictions on some products, and some products cannot be shipped to international destinations.
When you place an order, we will estimate shipping and delivery dates for you based on the availability of your items and the shipping options you choose. Depending on the shipping provider you choose, shipping date estimates may appear on the shipping quotes page.
Please also note that the shipping rates for many items we sell are weight-based. The weight of any such item can be found on its detail page. To reflect the policies of the shipping companies we use, all weights will be rounded up to the next full pound.

Product Description

Specifications

Attribute Value
Type Rolling Lobe
Automann Bellows# 1R14
Firestone Bellows# -
Goodyear Bellows# -
Contitech Bellows# 11 10.5D-21
Triangle Bellows# 8480
Load (Lbs) @80 PSI 10600
Load (Lbs) @100 PSI 62
Natural Freq. (CPM) 16.00
Bottom Plate Type Steel
Top Plate Hole/Stud Qty 2
Top Plate Dia. (A) 11.31
Top Plate C to C Dia. (B) 5.50
Bottom Plate Hole/Stud Qty 4
Bottom Plate Dia. (C) 10.24
Bottom Plate C to C Dia. (D) 5.56
Bottom Part # BS16272
Bottom Plate Alignment Parallel
Bumper Yes
Bracket No
Min. Height 7.50
Max. Height 24.10
Max. Dia. 15.00
Alternative Items
Automann # Image Product Name Brand Product Level
566.ER4152 Air Spring Rolling Lobe Air Spring Rolling Lobe
AB1R14-232 Air Spring Rolling Lobe Air Spring Rolling Lobe Hendrickson OE

Cross Reference

Name Part Number Notes
Contitech 11 10.5D-21 S 1063 Air Spring Rolling Lobe
Contitech 75269 Air Spring Rolling Lobe
Goodyear 1R14-152 Air Spring Rolling Lobe
Hendrickson Trailer C25319 Air Spring Rolling Lobe
Hendrickson Trailer C-25319 Air Spring Rolling Lobe
Hendrickson Trailer S25319 Air Spring Rolling Lobe
Hendrickson Trailer S-25319 Air Spring Rolling Lobe
