Continental Air Spring Rolling Lobe 77202

Continental Air Spring Rolling Lobe 77202

No Review
SKU: 566.CT77202
Vendor: Continental
Availability: Many In Stock
Regular price
$224.60
Regular price
$336.90
Sale price
$224.60
Ask An Expert

Free Shipping

Free standard shipping on orders over $249.

Excludes: Oversize Items (Brake Drums, Hubs, Body Parts, Exhaust, etc.)

Estimated to be delivered in 2-3 Business Days once shipped.

Typical lead time before shipped is 1-2 Business Days.

Free Returns

Learn More.

10 customers are viewing this product

Returns Policy

You may return most new, unopened items within 30 days of delivery for a full refund. We'll also pay the return shipping costs if the return is a result of our error (you received an incorrect or defective item, etc.).
You should expect to receive your refund within four weeks of giving your package to the return shipper, however, in many cases you will receive a refund more quickly. This time period includes the transit time for us to receive your return from the shipper (5 to 10 business days), the time it takes us to process your return once we receive it (3 to 5 business days), and the time it takes your bank to process our refund request (5 to 10 business days).
If you need to return an item, simply login to your account, view the order using the "Complete Orders" link under the My Account menu and click the Return Item(s) button. We'll notify you via e-mail of your refund once we've received and processed the returned item.

Shipping

We can ship to virtually any address in the world. Note that there are restrictions on some products, and some products cannot be shipped to international destinations.
When you place an order, we will estimate shipping and delivery dates for you based on the availability of your items and the shipping options you choose. Depending on the shipping provider you choose, shipping date estimates may appear on the shipping quotes page.
Please also note that the shipping rates for many items we sell are weight-based. The weight of any such item can be found on its detail page. To reflect the policies of the shipping companies we use, all weights will be rounded up to the next full pound.

Product Description

Specifications

Attribute Value
Type Rolling Lobe
Automann Bellows# 1DK18B
Firestone Bellows# 1T15LP-3
Goodyear Bellows# -
Contitech Bellows# 9 9M-13
Triangle Bellows# 4240
Load (Lbs) @80 PSI 5300
Natural Freq. (CPM) 12.00
Bottom Plate Type Plastic
Top Plate Hole/Stud Qty 3
Top Plate Dia. (A) 9.00
Top Plate C to C Dia. (B) 6.20
Bottom Plate Hole/Stud Qty 3
Bottom Plate Dia. (C) 9.45
Bottom Plate C to C Dia. (D) 4.11
Bottom Part # BS17208
Bottom Plate Alignment Parallel
Bumper Yes
Bracket No
Min. Height 6.34
Max. Height 18.82
Max. Dia. 10.59
Alternative Items
Automann # Image Product Name Brand Product Level
AB1DK18B-8478 Air Spring Rolling Lobe Air Spring Rolling Lobe Automann OE Aftermarket

Cross Reference

Name Part Number Notes
Contitech 77202 Air Spring Rolling Lobe
Contitech 9 9M-13 P 1283 Air Spring Rolling Lobe
Firestone 8478 Air Spring Rolling Lobe
Firestone 9146 Air Spring Rolling Lobe
Firestone 9259 Air Spring Rolling Lobe
Firestone 9589 Air Spring Rolling Lobe
Firestone W013588478 Air Spring Rolling Lobe
Firestone W01-358-8478 Air Spring Rolling Lobe
Firestone W013589146 Air Spring Rolling Lobe
Firestone W01-358-9146 Air Spring Rolling Lobe
Firestone W013589259 Air Spring Rolling Lobe
Firestone W01-358-9259 Air Spring Rolling Lobe
Firestone W013589589 Air Spring Rolling Lobe
Firestone W01-358-9589 Air Spring Rolling Lobe
Peterbilt 0301686 Air Spring Rolling Lobe
Peterbilt 301686 Air Spring Rolling Lobe
Peterbilt 0308424 Air Spring Rolling Lobe
Peterbilt 308424 Air Spring Rolling Lobe
