Description 15-7/16 C to E, Includes 462.ES6252R Adjustable End CH Axle Forward Model with E1200i Front Axle Specifications Attribute Value E to E (A) 14.500” Male/Female Male Shaft Side Thread (E) 1-1/4”-12 (RH) Where Used This item is not featured in any schematics. Applications There is no application data for...

Description 1.875 inch Offset Drop 12.69 in C to End, 1-7/8-12 in Stud, Minor Taper 1.08 inch Specifications Attribute Value Rod OD (A) 1-7/8” Type 4 Thread Pitch & Direction 12 (RH) Center to End (B) 13.000” Height of Taper (C) 2.670" Taper Minor Dia. (D) 1.080” Taper Major Dia....

Description Drag Link 15.340in C to C Mack Specifications Attribute Value C to C 15.340” C to C (B) N/A C to E 15.340” Type S E to E (A) 14.500” Shaft Dia. (A) 1.625” # Rep. Ends 1-1/4”-12 (RH) Male/Female Male Shaft Thread 1-1/4”-12 (RH) Shaft Side Thread (E)...

Description 1.875 inch Offset Drop 12.69 in C to End, 1-7/8-12 in Stud, Minor Taper 1.08 inch Specifications Attribute Value Rod OD (A) 1-7/8” Type 4 Thread Pitch & Direction 12 (LH) Center to End (B) 13.000” Height of Taper (C) 2.670" Taper Minor Dia. (D) 1.080” Taper Major Dia....

Description Tie Rod Metric Mack Specifications Attribute Value Rod OD (A) M30 Type 1 Thread Pitch & Direction 1.5 (RH) Center to End (B) 4.968" Height of Taper (C) 2.250" Taper Minor Dia. (D) 0.921" Taper Major Dia. (E) 1.031" Taper Length (F) 0.984" Stud Thread (G) M20-1.5 Drop (H)...

Description Drag Link 16.187in E to E Mack Specifications Attribute Value C to C (B) N/A C to E (B) 13.650” Type T-B E to E (A) 14.500” Male/Female Male Shift Dia. (C) 2.070” Shaft Side Thread (E) 1-1/8”-12 (RH) Pin Side Thread (D) 1-3/4”-18 (RH) Make Mack Where Used...

Description 38mm-1.5 X 140mm C to End with 80mm Head Diameter, with30mm-1.5 Shallow Castle Nut 80mm Taper Height C to Beginning of Threads 34.5MM Minor Taper Diameter and 38mm Major Taper Diameter Specifications Attribute Value Rod OD (A) M38 Type 1 Thread Pitch & Direction 1.5 (RH) Center to End...

Description Drag Link 35.390in C to C Mack Specifications Attribute Value C to C 35.390” C to C (B) N/A Type N-S E to E (A) 14.500” Shaft Dia. (A) 1.625” Male/Female Male Shaft Side Thread (E) 1-1/8”-12 (RH) Taper Pin Minor Dia.-1 (B) 1.080” Taper Pin Major Dia.-1 (C)...

Description Most FE Models Specifications Attribute Value Rod OD (A) M22 Type 1 Thread Pitch & Direction 1.5 (RH) Center to End (B) 5.433” Height of Taper (C) 1.850” Taper Minor Dia. (D) 0.728” Taper Major Dia. (E) 0.827” Taper Length (F) 0.984” Stud Thread (G) M14-1.5 Drop (H) N/A...

Description Drag Link Boot Specifications Attribute Value C to C (B) N/A E to E (A) 14.500” Male/Female Male Shaft Side Thread (E) 1-1/8”-12 (RH) Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name Part Number Notes...

Description Most FE Models Specifications Attribute Value Rod OD (A) M22 Type 1 Thread Pitch & Direction 1.5 (LH) Center to End (B) 5.433” Height of Taper (C) 1.850” Taper Minor Dia. (D) 0.728” Taper Major Dia. (E) 0.827” Taper Length (F) 0.984” Stud Thread (G) M14-1.5 Drop (H) N/A...

Description Drag Link 18.300in C to C Mack Specifications Attribute Value C to C (B) N/A Type T-A E to E (A) 14.500” Male/Female Male Shift Dia. (C) 1.875” Shaft Side Thread (E) 1-1/8”-12 (RH) Pin Side Thread (D) 1-1/2”-18 (RH) Make Mack Where Used This item is not featured...

Description 14.5in,1/1/8-12 Specifications No additional information available. Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name Part Number Notes Mack 13QC3262AP3 Mack Cross Tube End Trw L28LC5119B11 Mack Cross Tube End

Description Drag Link 16.750in E to E Mack Specifications Attribute Value C to C (B) N/A C to E (B) 14.400” Type T-B E to E (A) 14.500” Male/Female Male Shift Dia. (C) 2.070” Shaft Side Thread (E) 1-1/8”-12 (RH) Pin Side Thread (D) 1-3/4”-18 (RH) Make Mack Where Used...

Description Drag Link 32.250in E to E Mack Specifications Attribute Value C to C (B) N/A C to E (B) 29.810” Type T-B E to E (A) 14.500” Male/Female Male Shift Dia. (C) 2.065” Shaft Side Thread (E) 1-1/8”-12 (RH) Pin Side Thread (D) 1-3/4”-18 (RH) Make Mack Where Used...

Description Drag Link 16.872in E to E Mack Specifications Attribute Value C to C (B) N/A C to E (B) 14.375” Type T-B E to E (A) 14.500” Male/Female Male Shift Dia. (C) 2.070” Shaft Side Thread (E) 1-1/8”-12 (RH) Pin Side Thread (D) 1-3/4”-18 (RH) Make Mack Where Used...

Description Drag Link 16.750in E to E Mack Specifications Attribute Value C to C (B) N/A C to E (B) 14.700” Type T-B E to E (A) 14.500” Male/Female Male Shift Dia. (C) 1.875” Shaft Side Thread (E) 1-1/8”-12 (RH) Pin Side Thread (D) 1-1/2”-18 (RH) Make Mack Where Used...

Description Can Use 462.ES3252R Straight Pin Type Rod End or 462.ES431R Tappered Pin Type Tie Rod End MR Model 1-1/4-12 RH Internal Threads Small Dia 1.080in Large Tpaer Dia 1.250in Specifications Attribute Value C to C 37.180” C to C (B) N/A C to E 37.180” Type S E to...

Description Can Use 462.ES3252R Pin Type Rod End Specifications Attribute Value C to C 36.180” C to C (B) N/A C to E 36.180” Type S E to E (A) 14.500” Shaft Dia. (A) 1.625” # Rep. Ends 1-1/4”-12 (RH) Male/Female Male Shaft Thread 1-1/4”-12 (RH) Shaft Side Thread (E)...

Description Can Use 462.ES3252R Pin Type Rod End DMM Model and RD6 1-1/4-12 RH Internal Threads Small Dia 1.080in Large Tpaer Dia 1.250in Specifications Attribute Value C to C 14.250” C to C (B) N/A C to E 14.250” Type S E to E (A) 14.500” Shaft Dia. (A) 1.654”...
