Description Includes 462.ES6252R Specifications Attribute Value C to C 34.750” C to E or E to E 32.625” Type P-1 E to E (A) 14.500” Shaft Dia. (A) 1.654” # Rep. Ends 1 Male/Female Male Shaft Thread 1-1/4”-12 (RH) Shaft Side Thread (E) 1-1/8”-12 (RH) Taper Pin Minor Dia.-1 (B) 1.080”...

Description 17.64 inch C to C, 14.75 inch C to End Specifications Attribute Value C to C 17.640” C to E or E to E 14.750” Type P-1 E to E (A) 14.500” # Rep. Ends 1 Male/Female Male Shaft Thread 1-1/4”-12 (RH) Shaft Side Thread (E) 1-1/8”-12 (RH) Taper...

Description Drag Link 31.570in C to C Mack Specifications Attribute Value C to C 31.570” C to C (B) N/A Type N-S E to E (A) 14.500” Shaft Dia. (A) 1.500” Male/Female Male Shaft Side Thread (E) 1-1/8”-12 (RH) Taper Pin Minor Dia.-1 (B) 0.970” Taper Pin Major Dia.-1 (C)...

Description Drag Link 31.570in C to C Mack Specifications Attribute Value C to C 31.570” C to C (B) N/A Type N-S E to E (A) 14.500” Shaft Dia. (A) 1.500” Male/Female Male Shaft Side Thread (E) 1-1/8”-12 (RH) Taper Pin Minor Dia.-1 (B) 0.970” Taper Pin Major Dia.-1 (C)...

Description CHN, CHU, CXN Specifications Attribute Value C to C 31.570” C to C (B) N/A Type N-S E to E (A) 14.500” Shaft Dia. (A) 1.500” Male/Female Male Shaft Side Thread (E) 1-1/8”-12 (RH) Taper Pin Minor Dia.-1 (B) 0.970” Taper Pin Major Dia.-1 (C) 1.102” Taper Pin Length-1...

Description Midliner MS200, MS25, MS300 Includes 462.ES6234R Adjustable End Specifications No additional information available. Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name Part Number Notes Mack 4103-7485114935 Drag Link Mack 41037485114935 Drag Link Mack 5010130392 Drag...

Description MRU Cab Over Specifications Attribute Value C to C 39.900” Type P-N E to E (A) 14.500” Shaft Dia. (A) 2.000” Male/Female Male Shaft Side Thread (E) 1-1/8”-12 (RH) Taper Pin Minor Dia.-1 (B) 1.080” Taper Pin Major Dia.-1 (C) 1.250” Taper Pin Length-1 (D) 1.360” Taper Pin Thread-1...

Description 19-7/8in C to C, One Slotted Pin and One Tapered Pin, 1-1/4in Dia. Bar Specifications Attribute Value C to C (B) N/A E to E (A) 14.500” Male/Female Male Shaft Side Thread (E) 1-1/8”-12 (RH) Where Used This item is not featured in any schematics. Applications There is no...

Description Tie Rod Metric Mack Specifications Attribute Value Rod OD (A) M30 Type 1 Thread Pitch & Direction 1.5 (LH) Center to End (B) 4.968" Height of Taper (C) 2.250" Taper Minor Dia. (D) 0.921" Taper Major Dia. (E) 1.031" Taper Length (F) 0.984" Stud Thread (G) M20-1.5 Drop (H)...

Description CH Model with Axle Forward any Mack Front Axle Specifications Attribute Value C to C 18.500” C to C (B) N/A Type P-N E to E (A) 14.500” Male/Female Male Shaft Side Thread (E) 1-1/8”-12 (RH) Taper Pin Minor Dia.-1 (B) 1.080” Taper Pin Major Dia.-1 (C) 1.250” Taper...

Description T300 Specifications Attribute Value Rod OD (A) 1-1/8” Type 1 Thread Pitch & Direction 12 (RH) Center to End (B) 5.350” Height of Taper (C) 2.600” Taper Minor Dia. (D) 1.080” Taper Major Dia. (E) 1.250” Taper Length (F) 1.570” Stud Thread (G) 7/8”-14 Drop (H) N/A Item Used...

Description Can Try 462.ES5945L and 462.ES5945R Ends Specifications Attribute Value Rod OD (A) 1-1/8” Type 1 Thread Pitch & Direction 12 (LH) Center to End (B) 5.350” Height of Taper (C) 2.600” Taper Minor Dia. (D) 1.080” Taper Major Dia. (E) 1.250” Taper Length (F) 1.570” Stud Thread (G) 7/8”-14 Drop (H) N/A Item...

Description CH/CX Specifications No additional information available. Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name Part Number Notes Mack 13QC437M3 Drag Link Mack 25131817 Drag Link

Description Tie Rod End Isuzu NPR NKR LH Specifications Attribute Value Rod OD (A) M20 Type 1 Thread Pitch & Direction 1.5 (LH) Center to End (B) 4.095” Height of Taper (C) 1.732” Taper Minor Dia. (D) 0.709” Taper Major Dia. (E) 0.787” Taper Length (F) 0.866” Stud Thread (G)...

Description CH613 Specifications Attribute Value Type simple E to E (A) 14.500” Male/Female Male Shaft Side Thread (E) 1-1/8”-12 (RH) Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name Part Number Notes Mack 13AC3291M Drag Link Mack...

Description Tie Rod End Isuzu NPR NKR RH Specifications Attribute Value Rod OD (A) M20 Type 1 Thread Pitch & Direction 1.5 (RH) Center to End (B) 4.095” Height of Taper (C) 1.732” Taper Minor Dia. (D) 0.709” Taper Major Dia. (E) 0.787” Taper Length (F) 0.866” Stud Thread (G)...

Description Uses 463.ES431LS withRight Hand Thread DM Model with FAW20 and 592S Steering Gear Specifications Attribute Value C to C 18.750” C to C (B) N/A C to E or E to E 14.625” Type P-1 E to E (A) 14.500” Shaft Dia. (A) N/A # Rep. Ends 1 Male/Female...

Description Tie Rod End Use 462.ES9678L Specifications Attribute Value Type 1 Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name Part Number Notes Trw L24SV8205C13 Tie Rod End Use 462.Es9678L Volvo 85106747 Tie Rod End Use 462.Es9678L...

Description 26.0in C to C RB Model Specifications Attribute Value C to C (B) N/A E to E (A) 14.500” Male/Female Male Shaft Side Thread (E) 1-1/8”-12 (RH) Where Used This item is not featured in any schematics. Applications There is no application data for this product. Cross Reference Name...

Description OEM Type Version, Similar to 462.ES3252R Excpet Has 1/2in Orbital Lock Bolt Slot on Pin End Specifications Attribute Value Rod OD (A) 1-1/4” Type 2 Thread Pitch & Direction 12 (RH) Center to End (B) 5.813” Height of Taper (C) 2.000” Taper Minor Dia. (D) N/A Taper Major Dia....
